MMS6823 Product datasheet
|
Model number: |
MMS6823 |
|
Module Type： |
Data Acquisition Module |
|
Manufacture: |
EMERSON |
|
Condition： |
Brand New |
|
Range of Product: |
IMR 6000/00 System |
|
Lead time： |
In Stock |
|
Weight: |
0.28 kg |
|
HS CODE： |
8537101190 |
|
Dimension: |
6x18.8x12.8cm |
|
MOQ: |
1 |
|
Product Origin: |
USA |
|
System： |
DCS |
|
Discontinued on: |
Dec 31,2018 |
|
Communication Service: |
Ethernet router |
MMS6823 Functional Description
The EPRO MMS6823 custom processing module is engineered for high-performance applications in industrial environments. Designed to operate at 220V with an output frequency of 30 kHz, the EPRO MMS6823 ensures consistent performance even under demanding conditions, making it an ideal choice for complex automation systems. Its advanced design and robust construction guarantee reliable operation in harsh settings, delivering optimal functionality.
Certified for industrial use, the EPRO MMS6823 provides users with confidence, knowing that they are relying on durable and dependable equipment. Its custom processing capabilities offer tailored solutions to meet the specific needs of any application, enhancing system efficiency and accuracy. This adaptability makes it perfect for diverse industrial operations, from monitoring critical processes to controlling large-scale systems.
The compact design of the EPRO MMS6823 allows for straightforward installation and integration with minimal system modifications. Whether you need precision, flexibility, or durability, this module excels in providing the performance and reliability required for seamless operation.
For those seeking top-tier performance in industrial control systems, the EPRO MMS6823 delivers unmatched reliability and precision, ensuring successful outcomes in every operation.
If you have other request contact our team to get customized service
Call +86 18159889985 to be connected with our Manager Stella
Email to sales6@apterpower.com get your best quotation
For the quick assistance message us on WhatsApp at +86 18159889985 now!
|
EMERSON |
MMS6831 |
EMERSON |
A6210 |
EMERSON |
KJ2002X1-CA1 12P1509X092 VE3006 |
|
EMERSON |
MMS6823 |
EMERSON |
A6120 |
EMERSON |
KJ2002X1-BA1 12P1442X062 VE3002 |
|
EMERSON |
MMS6822 |
EMERSON |
A6110 |
EMERSON |
KJ2002X1-BA1 12P1442X042 VE3002 |
|
EMERSON |
MMS6250 |
EMERSON |
KJ2003X1-BB1 12P3439X032 VE3006 |
EMERSON |
KJ1501X1-BC3 12P3935X032 VE5009 |
|
EMERSON |
MMS6220 |
EMERSON |
KJ2003X1-BB1 12P3439X022 VE3006 |
EMERSON |
KJ1501X1-BC2 12P2186X042 VE5008 |
|
EMERSON |
MMS6211 |
EMERSON |
KJ2003X1-BB1 12P3439X012 VE3006 |
EMERSON |
KJ1501X1-BC2 12P2186X042 VE5008 |
|
EMERSON |
MMS6210 |
EMERSON |
KJ2003X1-BB1 12P3439X012 |
EMERSON |
KJ1501X1-BC1 12P2186X032 VE5008 |
|
EMERSON |
MMS6120 |
EMERSON |
KJ2003X1-BA2 12P2093X102 VE3005 |
EMERSON |
KJ1501X1-BB1 12P0678X042 VE5002 |
|
EMERSON |
MMS6110 |
EMERSON |
KJ2002X1-CA1 12P1509X102 VE3004 |
EMERSON |
KJ1501X1-BC1 12P2186X032 VE5008 |
|
EMERSON |
MMS3120/022-100 |
EMERSON |
KJ2002X1-CA1 12P1509X102 |
EMERSON |
KJ3222X1-BA1 12P2532X122 VE4033S2B1 |
IMR 6000/00 System frame
1.Component of the MMS 6000 Machine Monitoring System
2.Slots for adaptation of signal pro‐cessing periphery
Monitors: 10xMMS 6xxx*(selection: regarding assembly and functionality)
Logic card: e.g. MMS 6740,
Interface card:e.g: MMS 6824
3.External connection to the pe‐ riphery via 25-pole Sub-D connectors
4.System frame configuration via hardware bridges, solder bridges and configuration of the Dip- switches.
5.buildup of RS485 buslines for integration of all monitors
6.generation of a master-key si‐gnal by a key- monitor at the 1st monitor slot
7.change over between closedcircuit and open- circuit modevia solder bridges
Assembly and functionality:
The system frame IMR 6000/00 is a component of the epro MMS 6000 machine monitoring system. This consists of a 19” card frame and comprises the following card slots at the front side:
• 10 monitor slots for MMS 6000 series
• 2 slots for adaptation of one logiccard e.g. MMS 6740
• 1 slot for connection of an interface card e.g. MMS 6830, MMS 6831, MMS 6824 or MMS 6825
The following Monitors are supported of the system frame IMR 6000/00 with their basic functions:
MMS 6110, MMS 6120,
MMS 6125, MMS 6140,
MMS 6210, MMS 6220,
MMS 6310, MMS 6312,
MMS 6410.
The 1st monitor slot at the system frame offers the possibility to imply a key monitor and to relay these key signal to the other monitors. The rear of the system frame serves the purpose of:
• signal supply
• signal output for further processing
• parameterization of the system frame
The connection to the external periphery on the rear of the system frame is made by 25- pole SubD plugs. By integration of a corresponding interface card, if necessary, it`s possible to build up several RS485 buslines within one system frame. That`s the way to connect the monitors to one communication bus.
