Z7116 Product datasheet
Model number: |
Z7116 |
|
Module Type: |
Connection Cable |
Manufacture: |
HIMA |
|
Condition: |
Brand New |
Range of Product: |
HIQuad X system |
|
Lead time: |
In Stock |
Weight: |
0.08kg |
|
HS CODE: |
8537101190 |
Dimension: |
2x6x10.3cm |
|
MOQ: |
1 |
Product Origin: |
GERMANY |
|
System: |
DCS |
Discontinued on: |
active |
|
Communication Service: |
Ethernet router |
Z7116 Functional Description
The HIMA Z7116 Connection Module is designed for high-performance data exchange in industrial environments. Constructed from durable aluminum alloy, the Z7116 Analog Input Module offers both strength and a lightweight design, making it ideal for installation in a variety of industrial settings. Its robust build ensures reliability in demanding environments, providing long-lasting performance.
Supporting MODBUS and CANopen protocols, the Z7116 Cable Plug facilitates seamless integration with various automation systems, enabling efficient communication between different components on the production line. This makes it a versatile solution for industries requiring continuous data flow and control.
With an operating temperature range of -20°C to +60°C, the Z7116 Cable Plug is built to withstand the extreme conditions often found in industrial applications, ensuring reliable operation across diverse environments. It also features four RS-485 ports and two CAN ports, offering flexible connectivity options for connecting multiple devices and systems.
Compliant with CE, UL, and ISO 9001 standards, the Z7116 Connection Module guarantees high safety and quality standards, giving you peace of mind when integrating it into your existing infrastructure. Whether for expanding or upgrading automation systems, the Z7116 Analog Input Module delivers outstanding performance and versatility.
If you have other request contact our team to get customized service
