Z7138 Product datasheet
Model number: |
Z7138 |
|
Module Type: |
Cable Plug |
Manufacture: |
HIMA |
|
Condition: |
Brand New |
Range of Product: |
HIQuad X system |
|
Lead time: |
In Stock |
Weight: |
0.08kg |
|
HS CODE: |
8537101190 |
Dimension: |
2x6x10.3cm |
|
MOQ: |
1 |
Product Origin: |
GERMANY |
|
System: |
DCS |
Discontinued on: |
active |
|
Communication Service: |
Ethernet router |
Z7138 Functional Description
The HIMA Z7138 Cable Plug is a high-performance communication module designed for seamless integration into industrial control systems. Featuring a robust Ethernet interface, the Z7138 Cable Plug supports fast data transfer rates of up to 100 Mbps, making it ideal for real-time industrial communication and ensuring quick, efficient data transmission in complex automation networks.
Operating on a stable 24 V DC power supply, the HIMA Z7138 delivers reliable performance even in challenging industrial environments. Its compact, lightweight design allows for easy installation and integration into existing systems without the need for significant modifications or additional space, providing flexibility in various applications.
Certified to meet international safety standards, including CE and UL, the Advanced filtering Z7138 ensures both safety and reliability in industrial settings. This certification gives users confidence in the module's ability to perform consistently and securely, making it an excellent choice for industrial automation projects. Whether integrating it into machinery, robotics, or control systems, the Advanced filtering Z7138 delivers superior connectivity and performance.
If you have other request contact our team to get customized service
