AIP502 Product datasheet
Model number: |
AIP502 S1 |
|
Module Type: |
V-Net Coupler Module |
Manufacture: |
Yokogawa |
|
Condition: |
Brand New |
Range of Product: |
CENTUM VP |
|
Lead time: |
In Stock |
Weight: |
0.5kg |
|
HS CODE: |
8537101190 |
Dimension: |
5x25x12.8cm |
|
MOQ: |
1 |
Product Origin: |
JAPAN |
|
System: |
DCS |
Discontinued on: |
Dec 31,2018 |
|
Communication Service: |
Ethernet router |
AIP502 S1 Functional Description
The Yokogawa AIP502 S1 V-net Coupler Module is a vital component for industrial networks, providing robust connectivity and efficient data transfer. Its compact design minimizes interference while ensuring optimal performance in challenging industrial environments.
Engineered specifically for V-net networks, the AIP502 S1 V-net Coupler Module supports high-speed and reliable communication between various industrial devices. It is compatible with a wide range of protocols, including Modbus TCP/IP and OPC-UA, which facilitates seamless integration with existing automation systems, ensuring smooth and efficient operations.
The AIP502 S1 V-net Coupler Module features a durable connector that works with standard V-net repeaters, ensuring broad compatibility across devices from different manufacturers. Its broad operating temperature range of -20°C to +55°C guarantees reliable performance even in harsh industrial conditions, making it ideal for diverse environments.
With a versatile 16x I/O configuration, the AIP502 S1 V-net Coupler Module offers flexible input and output channels, allowing for customization to meet specific application needs. The DC 24V power supply ensures stable operation across a variety of industrial settings.
For ease of integration and monitoring, the module supports industry-standard protocols, simplifying setup and maintenance. The AIP502 S1 V-net Coupler Module is backed by Yokogawa's reputation for quality, making it a trusted choice for enhancing the efficiency and performance of industrial automation systems.
If you have other request contact our team to get customized service
