Allen-Bradley 1797-TB3 FLEX Ex I/O Terminal Base Module PLC Module

Allen-Bradley 1797-TB3
Allen-Bradley 1797-TB3
Allen-Bradley 1797-TB3

 1797-TB3 Product datasheet

Model number:

1797-TB3



Module Type:

FLEX Ex Terminal Base Units

Manufacture:

Allen-Bradley



Condition:

Brand New

Range of Product:

FLEX Ex I/O Module



Lead time:

In Stock

Weight:

0.24 kg



HS CODE:

8537101190

Dimension:

10x9.5x6cm



MOQ:

1

Product Origin:

USA



System:

PLCS

Discontinued on:

June 30,2016



Communication Service:

Ethernet router



1797-TB3 Functional Description

The ABB 1797-TB3 Terminal Base Unit is designed for unmatched reliability in demanding industrial environments. With its compact design and robust construction, the 1797-TB3 ensures long-lasting performance even in critical applications where uptime is essential. Its durable build makes it a trusted choice for industries that require dependable electrical connections.

Featuring an impressive operating temperature range from -20°C to +60°C, the 1797-TB3 can perform reliably in a variety of industrial settings, including those with extreme climate conditions. This flexibility allows it to be used across a wide spectrum of applications.

Equipped with an efficient terminal block, the 1797-TB3 facilitates quick and easy wiring, minimizing installation time and reducing downtime. Its user-friendly design enhances operational efficiency by streamlining setup and maintenance processes.

With a current rating of 10A and compatibility with a 24V DC power supply, the 1797-TB3 is versatile enough to handle the electrical demands of diverse automation systems. Featuring an IP20 rating, the unit is protected against dust and minor splashes, ensuring reliable performance in harsh environments. The 1797-TB3 also boasts a standard panel mount design for secure, space-saving installation, improving the overall layout of your control panel or enclosure.


If you have other request contact our team to get customized service


  •       One Year Warranty

    We offer a one-year warranty for any quality issues with our products. If you encounter any defects or malfunctions during this period, please contact us for prompt resolution. Our warranty covers repairs or replacements, ensuring your satisfaction and peace of mind.

  •         Shipping & Delivery

    We have 10 years experience with leading logistics companies like FedEx, DHL, and SF, ensuring efficient and reliable shipping solutions. Our extensive experience in working with these carriers allows us to offer fast, secure delivery services, tailored to meet the diverse needs of our customers.
  • #

                Payment Method

    We accept a variety of payment methods, including T/T Bank Transfer, Alipay, and more, providing flexible options to suit our customers' preferences. This ensures a convenient and secure transaction process for all orders.

How Can I Get Your Support?
Call +86 18159889985 to be connected with our Manager Stella
     Email to sales6@apterpower.com get your best quotation
    For the quick assistance message us on WhatsApp at +86 18159889985 now!
    You can also reach me via Skype: live:ariatang111 or WeChat: zxd18159889985!




Allen Bradley

1797-TB3

Allen Bradley

1794-OB16P

Allen Bradley

1794-IE4XOE2

Allen Bradley

1797-IE8NF

Allen Bradley

1794-OB16

Allen Bradley

1794-IE4X0E2

Allen Bradley

1794-VHSC

Allen Bradley

1794-OA8I

Allen Bradley

1794-IB8

Allen Bradley

1794-TBN

Allen Bradley

1794-L34

Allen Bradley

1794-IB16XT

Allen Bradley

1794-TB3S

Allen Bradley

1794-IV16

Allen Bradley

1794-IB16D

Allen Bradley

1794-TB2

Allen Bradley

1794-IRTB

Allen Bradley

1794-IB16

Allen Bradley

1794-PS1

Allen Bradley

1794-IRT8XT

Allen Bradley

1794-IA8

Allen Bradley

1794-OF41

Allen Bradley

1794-IM8

Allen Bradley

1794-AENTR

Allen Bradley

1794-OB8EP

Allen Bradley

1794-IF4I

Allen Bradley

1793-OB16P

Allen Bradley

1794-OB16PXT

Allen Bradley

1794-IE8H

Allen Bradley

1791-OB32





FLEX Ex Terminal Base Units Introduction


FLEX Ex combines a terminal strip and intrinsic-safety isolation with an I/O interface. Use the terminal strip on the terminal base to wire your field devices directly. The FLEX Ex design also offers these features:

• modularity for distributed IS systems

• all of the features of a larger, rack-based system

• installation near the field devices to reduce wiring costs and complexity

• terminations for field wiring eliminating the need for marshalling or extra terminal strips

• ControlNet-based networking solution in the hazardous area with ControlNet Ex products

• DIN-rail mounting



FLEX Ex provides additional value if system problems develop. The terminal base lets you remove and insert I/O modules under power without rewiring or disrupting your system. Combining your field-wiring terminations, IS isolation, and the I/O interface into the same location saves you time, money, and makes your system easier to maintain and troubleshoot. Additional benefits include:

• galvanic isolation between the I/O backplane, input circuitry, and power supply

• dual-fault protection IS circuits provide the highest fault tolerance

• I/O circuitry provides full IS field-device protection

• the modules themselves are IS protected for installation in hazardous environments FLEX Ex I/O modules may be removed and inserted while operating under power. Network module maintenance and cable connections can be made in the hazardous area while the system is in operation and the area is hazardous.

FLEX Ex Typical Configurations


The following are typical configurations of FLEX Ex I/O in an intrinsically safesystem:

FLEX Ex I/O modules are interfaced through a ControlNet Ex I/O adapter module to a coax ControlNet segment that is confined to the hazardous area. This coax ControlNet Ex segment is interfaced through ControlNet Ex coax drop repeater module and ControlNet Ex fiber media port adapter to a fiber-optic ControlNet segment, which is fed through from the safe area. A FLEX Ex power supply powers the repeater module, fiber media port adapter, ControlNet Ex I/O adapter module, and I/O modules individually. This configuration is best for long distances and a large number of nodes.

• The FLEX Ex ControlNet barrier allows connection to a ControlNet Ex I/O adapter module in the hazardous area via coax directly from the safe area. The barrier is mounted in the safe area. This is more economical for intermediate distances and nodes.

• Sensors and actuators in a hazardous area can be connected to FLEX Ex I/O modules, which are connected through a bus isolator module and connector to a FLEX I/O adapter in a safe area thus allowing connectivity to DeviceNet, ControlNet, Universal Remote I/O, and EtherNet/IP. This configuration may be most economical for low-point applications or when networks other than ControlNet are required.

FLEX Ex I/O modules in a hazardous area can be connected through an extender cable to a FlexBus feed-through connector in an explosion-proof enclosure. Inside the enclosure, the feed-through connector is connected through a FLEX Ex extender cable, and then a bus isolator module and connector, to a FLEX I/O adapter.
