3500/15 106M1079-01 Product datasheet
Model number: |
3500/15 106M1079-01 |
|
Module Type: |
AC and DC Power Supply module |
Manufacture: |
Bently Nevada |
|
Condition: |
Brand New |
Range of Product: |
3500 system |
|
Lead time: |
In Stock |
Weight: |
1.2kg |
|
HS CODE: |
8537101190 |
Dimension: |
5x25x12cm |
|
MOQ: |
1 |
Product Origin: |
USA |
|
System: |
TSI |
Discontinued on: |
active |
|
Communication Service: |
Ethernet router |
3500/15 106M1079-01 Functional Description
If you have other request contact our team to get customized service
Bently Nevada |
3500/33 149986-01 |
Bently Nevada |
3500/20 125744-02 |
Bently Nevada |
3500/45 176449-04 |
Bently Nevada |
3500/32M 149986-02 |
Bently Nevada |
3500/15 133292-01 |
Bently Nevada |
3500/45 176449-04 |
Bently Nevada |
3500/32 125712-01 |
Bently Nevada |
3500/60 163179-01 |
Bently Nevada |
3500/45 140072-04 |
Bently Nevada |
3500/25 149369-01 |
Bently Nevada |
3500/60 133811-01 |
Bently Nevada |
3500/44M 176449-03 |
Bently Nevada |
3500/25 149369-01 |
Bently Nevada |
3500/54M 286566-01 |
Bently Nevada |
3500/42M 176449-02 |
Bently Nevada |
3500/23E |
Bently Nevada |
3500/53 133388-01 |
Bently Nevada |
3500/42M 140734-02 |
Bently Nevada |
3500/22M 288055-01 |
Bently Nevada |
3500/50M 286566-02 |
Bently Nevada |
3500/42E 289837-01 |
Bently Nevada |
3500/22M 138607-01 |
Bently Nevada |
3500/50 133388-02 |
Bently Nevada |
3500/40M 176449-01 |
3500 System 3500/15 Introduction
The 3500/15 AC and DC Power Supplies are half-height modules and must be installed in designated slots on the left side of the rack. The 3500 rack can contain one or two power supplies with any combinations of AC and DC. Either supply can power a full rack.
When two power supplies are installed in a rack, the one in the lower slot acts as the primary supply, and the other in the upper slot acts as the backup supply. If installed, the second supply is the backup for the primary one.
Removing or inserting either power supply module does not disrupt operation of the rack as long as a second power supply is installed.
The 3500/15 AC and DC Power Supplies accepts a wide range of input voltages and converts them to voltages acceptable for use by other 3500 modules. The following power supplies are available with the 3500 Series Machinery Protection System:
1. Universal AC Power
2. High Voltage DC Power Supply
3. Low Voltage DC Power Supply
