1785-L80B Product datasheet
Model number: |
1785-L80B |
|
Module Type: |
CPU Module |
Manufacture: |
Allen-Bradley |
|
Condition: |
Brand New |
Range of Product: |
PLC-5 |
|
Lead time: |
In Stock |
Weight: |
1.32k |
|
HS CODE: |
8537101190 |
Dimension: |
4.8x15.2x27.3cm |
|
MOQ: |
1 |
Product Origin: |
USA |
|
System: |
PLC |
Discontinued on: |
July 31, 2017 |
|
Communication Service: |
Ethernet router |
1785-L80B Functional Description
The 1785-L80B Controller Module is a key component of the Allen-Bradley PLC-5 series, designed to integrate local, extended, and remote I/O modules into a single control system. The 1785-L80B Controller Module features four configurable ports—channels 1A, 1B, 2A, and 2B—that can operate as remote I/O scanners, remote I/O adapters, or DH+ communication interfaces. These ports enable the 1785-L80B to facilitate efficient communication within the control system.
Using the Data Highway Plus (DH+) link, the 1785-L80B Controller Module enables seamless peer-to-peer communication between PLC-5 controllers and other system components. Remote I/O connections allow real-time data exchange between the controller, I/O devices, and operator interfaces. The 1785-L80B Controller Module also supports multiple protocols, including ASCII and DF1, via its 25-pin RS232C connector (channel 0) for easy programming and monitoring.
On the front panel, the 1785-L80B Controller Module features status indicators like PROC, FORCE, and COMM to provide real-time feedback on the controller’s operation. These indicators, along with the four communication channels, make the 1785-L80B a versatile and reliable choice for complex automation tasks.
