1785-LT3 Product datasheet

1785-LT3 Functional Description

The Allen-Bradley 1785-LT3 module is a versatile and powerful device featuring 512 I/O points. It comes with both a DH+ Channel and a Remote I/O Channel (Adapter Only), providing robust communication capabilities. The DH+ connection enables remote programming and facilitates data transfer between PLCs and higher-level computers, making it ideal for programming processors and connecting up to 64 stations on the DH+ link.

Designed to operate within a temperature range of 0-60°C (32-140°F), the Allen-Bradley 1785-LT3 module  ensures reliable performance under normal conditions. However, exposure to temperatures outside this range (-40-85°C or -40-185°F for non-operating conditions) can damage the module. It has a memory capacity of 6K words and a backplane current requirement of 2.5A at 5V DC, making it suitable for various industrial applications.

Additionally, the Allen-Bradley 1785-LT3 module  includes a Control Coprocessor Expansion Port, providing enhanced control capabilities. It also supports remote I/O transmission at 57.6 kbps. The module comes with a sequential function chart (SFC) and specialized programming features, enabling users to develop, enter, and test their programs efficiently. Once testing is complete, the program can be applied directly to the system.
