3BSE018298R1 DSDO115A Product datasheet
Model number: |
3BSE018298R1 DSDO115A |
|
Module Type: |
Bus Extender Board |
Manufacture: |
ABB |
|
Condition: |
Brand New |
Range of Product: |
S100 I/O |
|
Lead time: |
In Stock |
Weight: |
0.32kg |
|
HS CODE: |
8537101190 |
Dimension: |
2x24.9x24.4cm |
|
MOQ: |
1 |
Product Origin: |
SWEDEN |
|
System: |
DCS |
Discontinued on: |
Active |
|
Communication Service: |
Ethernet router |
3BSE018298R1 DSDO115A Functional Description
The ABB DSDO115A 3BSE018298R1 is a high-performance 32-channel digital output board, specifically engineered for use with ABB's Advant OCS and S100 I/O systems. This advanced module is a versatile solution, suitable for a wide range of industrial applications, including process control, machine automation, and building automation.
The ABB DSDO115A 3BSE018298R1 delivers reliable, high-speed digital outputs, ensuring precise control over various machinery and processes. Its robust design allows it to perform efficiently in demanding industrial environments, making it an ideal choice for systems requiring continuous, stable operation.
This digital output board enhances flexibility by supporting easy integration with existing control systems. The ABB DSDO115A 3BSE018298R1 is compatible with a variety of automation setups, enabling seamless communication and expanding the capabilities of your automation infrastructure.
With 32 output channels, the ABB DSDO115A 3BSE018298R1 ensures efficient handling of complex automation tasks, reducing wiring complexity and improving overall system performance. Its versatile nature, combined with dependable performance, makes it a valuable asset in modern industrial control and automation systems.
Features:
1.32 isolated digital outputs: Each channel can be independently configured as sinking or sourcing, providing flexibility for driving various devices.
2.High current capacity: Each output can handle up to 2 Amps, making it suitable for controlling powerful devices.
3.Fast switching speed: The board offers fast response times for applications requiring rapid switching.
4.Diagnostic LEDs: Each channel has an LED indicator for easy troubleshooting and status monitoring.
5.Optional redundancy: Redundancy can be achieved by using two boards, enhancing system availability.
6.RoHS compliance: Meets environmental safety standards.
