1756-SIM Product datasheet
Model number: |
1756-SIM |
|
Module Type: |
Input/Output Simulator Module |
Manufacture: |
Allen-Bradley |
|
Condition: |
Brand New |
Range of Product: |
ControlLogix |
|
Lead time: |
In Stock |
Weight: |
0.3kg |
|
HS CODE: |
8537101190 |
Dimension: |
3.6x13x14cm |
|
MOQ: |
1 |
Product Origin: |
USA |
|
System: |
PLC |
Discontinued on: |
December 31, 2012 |
|
Communication Service: |
Ethernet router |
1756-SIM Functional Description
The 1756-SIM Simulator Module is used to simulate discrete I/O in Studio 5000 Logix Emulate, providing an essential tool for testing and debugging logic programs without the need for physical hardware. In Studio 5000 Logix Emulate, the 1756-SIM Simulator Module is designed to function within the virtual chassis, offering both inputs and outputs that can be manipulated to simulate real-world conditions. This allows users to validate their control systems, ensuring proper function and performance before deployment.
In Studio 5000 Logix Designer, the same simulated I/O functionality is represented by the 1756-SIM Simulator Module. The 1756-SIM Simulator Module is unique in that it is the only type of I/O that can be simulated within Studio 5000 Logix Emulate, making it an indispensable tool for virtual testing in control system design. It allows developers to create and troubleshoot logic programs by mimicking the behavior of actual input and output devices in a controlled environment.
The 1756-SIM Simulator Module simplifies the process of simulation by providing a straightforward way to generate and manage I/O signals within the virtual control system. This capability not only reduces the need for physical hardware during the development and testing phases but also speeds up the overall design process. By incorporating the 1756-SIM Simulator Module, engineers can ensure their control programs are fully optimized and error-free before integration with live systems.
In summary, the 1756-SIM Simulator Module is crucial for simulating discrete I/O in both Studio 5000 Logix Emulate and Logix Designer, providing a cost-effective and efficient solution for developing and testing control logic.
If you have other request contact our team to get customized service
