GE Fanuc IC694MDL940 Voltage Output module

Inquiry now

IC694MDL940 Product datasheet

Model number:	IC694MDL940	Module Type：	Voltage Output module
Manufacture:	GE	Condition：	Brand New
Range of Product:	PACSystems™ RX3i	Lead time：	In Stock
Weight:	0.52 kg	HS CODE：	8537101190
Dimension:	13x6.8x13.1cm	MOQ:	1
Product Origin:	USA	System：	PLC
Discontinued on:	Active	Communication Service:	Ethernet router

IC694MDL940 Functional Description

The IC694MDL940 is a 16-point relay output module from the PACSystems RX3i series by Emerson Automation, previously manufactured by GE Intelligent Platforms. This module, occupying a single slot in the backplane, is designed for controlling various devices like motor starters, solenoids, and indicators. It features four groups of four relay outputs, each using normally open (N.O.) or Form A contacts. The outputs are rated for a maximum load of 2 Amps per channel, with a total maximum output current of 4 Amps per group. The minimum load is 10 mA, and the module can handle an inrush current of up to 5 Amps.

The IC694MDL940 relay output module is powered by a 24V DC relay bus, with a maximum current draw of 135 mA from the backplane and 7 mA from the 5V DC bus. The module provides 16 status LEDs to indicate the status of each output channel, helping with easy diagnostics. Each relay output has a response time of 15 ms for signal transitions. Importantly, the module does not have internal fuses for channel protection, so external fuses should be installed by users to prevent damage.

IC694MDL940 relay output module offers robust isolation with 250 VAC continuous and 1500 VAC for 1 minute isolation ratings from field to backplane, as well as 250 VAC continuous isolation between channels. It is compatible with RX3i PACSystems CPUs and can be installed in any I/O slot of the RX3i backplane.

The IC694MDL940 relay output module is highly reliable for industrial applications, offering precise control over output devices with excellent electrical isolation and robust current handling.
