IC698CPE020-JX Product datasheet
|
Model number: |
IC698CPE020-JX |
|
Module Type： |
PLC Module |
|
Manufacture: |
GE |
|
Condition： |
Brand New |
|
Range of Product: |
Rx7i PACsystem |
|
Lead time： |
In Stock |
|
Weight: |
0.8kg |
|
HS CODE： |
8537101190 |
|
Dimension: |
4x8x29.2cm |
|
MOQ: |
1 |
|
Product Origin: |
USA |
|
System： |
PLC |
|
Discontinued on: |
Active |
|
Communication Service: |
Ethernet router |
IC698CPE020-JX Functional Description
The General Electric IC698CPE020-JX RX7i CPU is a versatile and powerful controller from GE, part of the PACSystems RX3i series, designed to provide high-performance control and automation solutions for industrial applications. As a highly reliable and flexible programmable logic controller (PLC), the General Electric IC698CPE020-JX PACSystems offers advanced processing capabilities and supports extensive I/O modules. Its architecture enables seamless integration with other GE automation products, ensuring efficient operations in complex systems.
With an 800 MHz processor and 512 MB of memory, the GE IC698CPE020-JX CPU Reference delivers fast processing speeds for demanding tasks. The controller's support for multiple communication protocols allows for easy connectivity with various devices, including remote I/O systems and field devices. Additionally, the IC698CPE020-JX Central Processing Unit Module is built to withstand harsh industrial environments, ensuring long-term durability and reliability.
In summary, the IC698CPE020 PACSystems* RX7i is ideal for applications requiring high-speed, flexible control solutions, offering extensive connectivity options and robust performance to meet the needs of modern industrial automation systems.
If you have other request contact our team to get customized service
Call +86 18159889985 to be connected with our Manager Stella
Email to sales6@apterpower.com get your best quotation
For the quick assistance message us on WhatsApp at +86 18159889985 now!
|
